PTMS-FP-1250 Membrane Filter Press
The PTMS-FP-1250 is a 1250×1250 high-pressure membrane (diaphragm) filter press for dewatering mineral, ceramic and similar slurries. Plate count is 50 membrane plates plus 50 matching chamber plates; feed pressure up to 1.6 MPa and squeeze pressure up to 2.0 MPa.
- FOSHAN POWTECH / PTMS processing equipment
- Specs matched to mineral and ceramic process lines
- Installation guidance and remote support for overseas buyers
Specifications
1250×1250 high-pressure membrane filter press: feed ≤1.6 MPa, squeeze ≤2.0 MPa, 50 membrane + 50 matching plates, PLC control, Q235 frame.
| Parameter | Value |
|---|---|
| Model | PTMS-FP-1250 (1250 series high-pressure membrane filter press) |
| Filter plate outer size | Chamber plate 1250×1250×70 mm; membrane plate 1250×1250×78 mm |
| Working pressure | Feed ≤1.6 MPa; squeeze ≤2.0 MPa |
| Hydraulic cylinder | Single 400 |
| Filtrate discharge | Dual open flow |
| Compression plate stroke | 700 mm |
| Plate pulling | Motorized plate pull |
| Chamber depth | 35 mm |
| Plate count | 50 membrane + 50 matching plates |
| Plate material | High-pressure reinforced polypropylene |
| Filter cloth | Non-woven or monofilament (per application) |
| Total power | 7.5 + 1.1 kW intermittent |
| Protection | IP55 |
| Oil pump | Jiangsu Hengyuan / Jiangsu Jinda class |
| Hydraulic valves | Beijing Huade class |
| Control | PLC programmed for press body actions |
| Frame coating | Anti-rust paint |
| Frame material | Q235 |
| Operating temperature | ≤60 °C |
| Plates pulled per cycle | 1 |
| Application note | Single-machine equipment; capacity depends on customer demand. For about 5,000 t/month domestic ceramic/mineral lines, a typical layout uses 4–6 units. |
| Warranty | 12 months (standard PTMS product warranty) |
Product details
The PTMS-FP-1250 is a PLC-controlled high-pressure membrane filter press in the 1250×1250 series. Chamber plates are 1250×1250×70 mm and membrane plates 1250×1250×78 mm, with a 35 mm chamber depth. Working pressures are feed ≤1.6 MPa and squeeze ≤2.0 MPa. The machine uses a single 400 hydraulic cylinder, dual open-flow filtrate discharge, 700 mm compression-plate stroke and motorized plate pulling (one plate per cycle). Fifty membrane plates plus fifty matching plates are high-pressure reinforced polypropylene; filter cloth is non-woven or monofilament per application.
Total intermittent power is 7.5 + 1.1 kW (IP55). The frame is Q235 with anti-rust paint; operating temperature ≤60 °C. Oil pump and hydraulic valves are industrial class (Jiangsu Hengyuan / Jiangsu Jinda class pump; Beijing Huade class valves). Control is PLC-programmed for press-body actions.
Applications
Dewatering of mineral and ceramic slurries after wet magnetic separation or washing—for example kaolin, feldspar and ceramic slip lines. Capacity depends on feed solids, cake moisture target and cycle time; for about 5,000 t/month domestic-type lines, a typical layout uses 4–6 units.
Configuration
Ask for a layout matched to your slurry density and cake moisture target. We supply the press as FOSHAN POWTECH / PTMS processing equipment with standard PTMS warranty and overseas support.
