PTMS-1200-3S Vibratory Sieve
The PTMS-1200-3S is a three-deck vibratory sieve (vibrating screen) for grading dry powders and granules in mineral, ceramic and related process lines. Contact parts are 304 stainless steel; the vibrating body and bottom bucket are carbon steel.
- FOSHAN POWTECH / PTMS processing equipment
- Specs matched to mineral and ceramic process lines
- Installation guidance and remote support for overseas buyers
Specifications
Three-deck vibratory sieve with 304 stainless contact parts, L-shaped mesh frame with bouncing balls, and motor power typically 1.5–4.175 kW depending on configuration.
| Parameter | Value |
|---|---|
| Model | PTMS-1200-3S |
| HS code | 8474100000 |
| Contact parts | 304 stainless steel |
| SS cover plate thickness | 1.5 mm |
| SS sieve frame plate thickness | 2.0 mm |
| Mesh frame | SS L-shaped mesh frame with perforated plates and bouncing balls |
| Vibrating component | Carbon steel, 4.0 mm |
| Bottom bucket | Carbon steel, 3.0 mm |
| Motor power | Per configuration (typical range 1.5–4.175 kW) |
| Decks | 3-layer (3S) |
| Warranty | 12 months (standard PTMS product warranty) |
Product details
The PTMS-1200-3S vibratory sieve screens dry powders and granules on three decks. Product-contact surfaces use 304 stainless steel (cover plates 1.5 mm, sieve frame plates 2.0 mm). An L-shaped stainless mesh frame with perforated plates and bouncing balls keeps the screen clear during operation. The vibrating component (4.0 mm carbon steel) and bottom bucket (3.0 mm carbon steel) form the structural body. Motor power is selected per configuration; the typical published range is 1.5–4.175 kW.
Applications
Used for grading and impurity screening ahead of or after magnetic separation on kaolin, feldspar, quartz and ceramic lines. Pair with a PTMS magnetic separator when the process needs both size classification and iron removal.
Free sample / sizing
Tell us your particle size range, moisture and target throughput. We recommend mesh sizes and deck arrangement, and can run a free material sample test on matching magnetic separators in the same line.
